Name: Kinco SMC60S-0040-30QAK-5BSU
Brand: Kinco
SKU: SMC60S-0040-30QAK-5BSU
Availability: InStock

‹

›

Low-voltage servo motor (60 mm)

Kinco

SMC60S-0040-30QAK-5BSU

A 400 W low-voltage brushless servo motor on a 60 mm flange, rated 3,000 rpm at 48 V DC. Delivering 1.27 N·m continuous and 3.81 N·m peak torque, it provides compact, efficient drive power for lighter-duty FlyWei AMRs.

↓ Request datasheet (PDF)

🎯

400 W, 60 mm flange

📡

3,000 rpm rated (3,500 rpm max)

🔌

1.27 N·m rated / 3.81 N·m peak

🛡️

48 V DC low-voltage class

📦

IP65 body, insulation class F

Product parameters

⚡

400 W

Rated power

⚡

48 V

Voltage (DC)

🔧

1.27 N·m

Rated torque

🔧

3000 rpm

Rated speed

🔧

IP65

Protection

Full specifications

Type	Low-voltage brushless servo motor, SMC60S series, small inertia
Rated power	400 W
Rated voltage (DC link)	48 V DC
Rated torque	1.27 N·m (180 oz-in)
Maximum (peak) torque	3.81 N·m (540 oz-in)
Rated standstill torque	1.40 N·m (198 oz-in)
Rated speed	3000 rpm
Maximum speed	3500 rpm
Rated current	10.1 A
Maximum (peak) current	30.3 A
Rated standstill current	11.1 A
Flange size	60 mm (60 × 60 mm)
Number of pole pairs	3
Insulation class	F
Protection level	IP65 body, IP54 shaft seal
Shaft	Keyed shaft
Max radial force	180 N
Max axial force	90 N
Operating temperature	–20 °C to 40 °C (non-freezing)
Cooling	Totally enclosed, non-ventilated
