SCB-2000EU

CE Certification, Superb Load Capacity, Flexible Expansion

The SCB-2000EU is the premium CE-certified autonomous counterbalanced forklift for European markets. Its modular architecture allows flexible expansion — adding optional sensors, camera systems, and attachment interfaces for specialised loads. With 2,000 kg capacity and a robust safety suite, it is the preferred choice for European distribution and manufacturing facilities requiring certified automation.

📦
CE Certification, Safety Guaranteed
AI Carrier Recognition, Highly Precise and Efficient
🧭
12-15h Long Endurance, Quick Battery Swap
🛡️
360° Scanning Range, Multi-layer Safety Protection
🔗
Flexible Customization with 3 Options
🔋
Ultrasonic Detection, Safe Stacking

Interactive 3D Model

Drag to rotate · Scroll to zoom

Product parameters

📦
2000
Rated Load Capacity (kg)
🔋
12~15
Comprehensive Battery Life (h)
📏
3000 / 4000
Standard Lifting Height (mm)
🔄
1585
Minimum Turning Radius (mm)
🎯
±10, ±1
Positioning Accuracy (mm,°)
📦
1.0 / 1.5
Driving Speed (Full load / No load) (m/s)

Full specifications

● Standard    ○ Optional    – None
Basic parametersOperation typeAutomatic navigation
Navigation typeLaser SLAM
Pallet typeOpen pallet / closed pallet
Rated load capacity2000 kg (4409.24 lb)
Load center distance500 mm (19.69 in)
Weight (with battery)3230 / 3410 kg (7117.92 / 7517.56 lb)
Standard lifting height3000 / 4000 mm (118.11 / 157.48 in)
Forklift dimensions: L x W x H2839 x 1161x2095 / 2851 x 1161 x2105mm (111.77 x 45.71 x 82.48 / 112.24 x 45.71 x 82.87 in)
Fork dimensions: L x W x H1220 x 133 x 40 mm (48.03 x 5.24 x 1.57 in)
Fork outer width400 mm to 700 mm (15.75 to 27.56 in)
Right-angle stacking aisle width, pallet 1000×1200 (1200 placed along the fork)2997+200 / 3009+200 mm (117.99+7.87 / 118.46+7.87 in)
Right-angle stacking aisle width, pallet 800×1200 (1200 placed along the fork)2985+200 / 2997+200 mm (117.52+7.87 / 117.99+7.87 in)
Right-angle stacking aisle width, pallet 1000×1000 (1000 placed along the fork)2985+200 / 2997+200 mm (117.52+7.87 / 117.99+7.87 in)
Minimum turning radius1585 mm (62.40 in)
Ambient temperature and humidity rangeTEMP:0°C to 50°C / RH: 10% to 90%, no compression, no condensation (TEMP: 32F to 122F / RH: 10% to 90%, no compression, no condensation)
Performance parametersDriving speed: full load / no load1.0 / 1.5 m/s (3.28 / 4.92 ft/s)
Passability (slope / step / gap)<5% / 10 mm / 30 mm (<5% / 0.39 in / 1.18 in)
Navigation position accuracy±10 mm (± 0.39 in)
Navigation angle accuracy± 1°
Battery parametersBattery specifications48 V / 315 Ah (lithium iron phosphate)
Comprehensive battery life12 h to 15 h
Charging time (10% to 80%)3 h to 5 h
Charging methodManual / Automatic
Function configurationsLidar number1 (SLM-SLE4248 +3 (SICK HV) or 1 (SLM-SLE4248) +2 (SICK HV) +1 (SLD40)
Wi-Fi roaming
3D obstacle avoidance
Pallet recognition
Cage stack
High shelf pallet recognition
Pallet stack
HMI display
Safety configurationsE-stop button
Sound and light indicator
Braking distance: 1 m/s / 1.5 m/s≤30 cm / ≤50 cm (≤11.81 in / ≤19.69 in)
360° laser protection
Bumper strip-
Fork height protection
CertificationsISO 3691-4
EMC
UN38.3
RED
Dimensions (mm)
SCB-2000EU dimensioned drawing (mm)

Typical Applications

European Manufacturing
Distribution Centers
Flexible Automation Deployments
