SFL-CBD15 & SFL-CBD15-CE
CECertified
Pallet TrucksAutonomous Pallet Truck

SFL-CBD15 & SFL-CBD15-CE

Ultimate Robot Body, Flexible Customization

The SFL-CBD15 is our flagship autonomous pallet truck, combining a robust 1,500 kg load capacity with precision laser SLAM navigation. Engineered for demanding logistics environments, it delivers 1.4 m/s travel speed while maintaining multi-layer safety compliance. The CE-certified variant (SFL-CBD15-CE) is fully approved for European markets and integrates with leading fleet management systems via Wi-Fi and cellular connectivity.

📦
Compact in Size, yet Capable of 1.5 T Load Capacity
360° Large Field of View, Multiple Safety Protection
🧭
3+ Carrier Types, Wide-angle and High-precision Recognition
🛡️
Speed up to 1.4 m/s, Mapping up to 400000 m²
🔗
Quick Charge, Quick Swap; Double Battery, Double Endurance
🔋
CE & Non-CE Versions, Available for Global Market

Interactive 3D Model

Drag to rotate · Scroll to zoom

Product parameters

📦
1500
Rated Load Capacity (kg)
🔋
8~10
Comprehensive Battery Life (h)
📏
205
Standard Lifting Height (mm)
🔄
1532
Minimum Turning Radius (mm)
🎯
±10, ±1
Positioning Accuracy (mm,°)
📦
1.4 / 1.4
Driving Speed (Full load / No load) (m/s)

Full specifications

● Standard    ○ Optional    – None
Basic parametersOperation typeAutomatic navigation, by manual control device
Navigation typeLaser SLAM
Pallet typeOpen pallet
Rated load capacity1500 kg
Load center distance600 mm
Weight (with battery)403 kg
Standard lifting height205 mm
Forklift dimensions: L x W x H1685 x 980 x 1906 mm
Fork dimensions: L x W x H1220 x (170+7) x 75 mm (7 mm wiring panel)
Fork outer width550 / 600 / 680 mm
Right-angle stacking aisle width, pallet 1000×1200 (1200 placed along the fork)2260+200 mm
Right-angle stacking aisle width, pallet 800×1200 (1200 placed along the fork)2220+200 mm
Right-angle stacking aisle width, pallet 1000×1000 (1000 placed along the fork)2230+200 mm
Minimum turning radius1532 mm
Ambient temperature and humidity rangeTEMP: 0°C to 50°C / RH: 10% to 90%, no compression, no condensation
Performance parametersDriving speed: full load / no load1.4 / 1.4 m/s
Passability (slope / step / gap)< 5% / 10 mm / 30 mm
Navigation position accuracy±10 mm
Navigation angle accuracy±1°
Battery parametersBattery specifications48 V / 46 Ah (lithium iron phosphate)
Comprehensive battery life8 to 10 h
Charging time (10% to 80%)1 h
Charging methodManual / Automatic
Function configurationsLidar number1(P+F OMD30M-R2000-B23-V1V1D-HD-1L) +2 (SICK nanoScan3 Core)
Wi-Fi roaming
3D obstacle avoidance
Pallet recognition
Safety configurationsE-stop button
Sound and light indicator
Braking distance: 1 m/s / 1.5 m/s1m / 2m
Fork height protection
CertificationsISO 3691-4
EMC / ESD
UN38.3
RED
Dimensions (mm)
SFL-CBD15 & SFL-CBD15-CE dimensioned drawing (mm)

Typical Applications

Pallet Transport
Cross-Docking
Goods-to-Dock
Manufacturing Lines
